Model

     LITH-JS

Working Power

     2400W

Voltage

     220V/110V selectable

Effective Calendering Width

    100-400mm selectable

Roller Size Optional

    100mm Dia. x 100mm W

    100mm Dia. x 200mm W

    100mm Dia. x 300mm W

    100mm Dia. x 400mm W

   Or customized roller diameter and rolling width

Hardness of roll surface

     HRC62, imported 9CR2MO steel roll material

Calendering Thickness

(Effective clearance)

     0~3 mm adjustable

Dial Gauge Accuracy

     0.01mm

Rolling Speed

    CVT, linear speed 0-8.5 m/min adjustable

Roller SurfaceFinish Degree

    Hard chromium plating never rusts

Roll surface quenching depth

          5mm

Max. Pressure

           5Ton

Heating Temperature

·        150°C Max. (< 1hr)

·        130°C Continuously

·         Recommended Heating Rate: 1.3°C/minute

          The heating temperature can be customized

 Operation environment

    Ar gas compatible

Temperature Control Accuracy

    +/-1°C
