Prismatic Cell Pack Assembly Plant

 /1000W-3000W Fiber Continuous Laser Welder For Prismatic Battery Connector Welding
Laser Welding Machine

1000W-3000W Fiber Continuous Laser Welder For Prismatic Battery Connector Welding

Contact Person：Louis Yang

Email: Louis@chinabatterymachine.com

Tel：+86 13003860308
Whatsapp: +86 13003860308
Wechat：18659217588

  • Item No.:

    LITH-DPH-1000ZD3-CW

  • Payment:

    Credit Card, Paypal, T/T , Western Union, LC

  • Shipping port:

    Xiamen Port

  • Lead Time:

    5 days

Product categories

New Products

  • Product Details

 1000W-3000W Fiber Continuous Laser Welder For Prismatic Battery Connector Welding



Principle Of Laser Welding:

After a series of processing, the laser emitted by the laser generator highly concentrates the energy in a very small range after focusing by the lens. If the processed material absorbs the laser better, the material in the irradiated area will rise rapidly because it absorbs the laser energy. According to different material properties(such as melting point, boiling point and temperature of chemical change), the workpiece will undergo a series of physical or chemical changes, such as melting, gasification, oxide formation, discoloration and so on.



Main Configuration Table:

Name

Qty

DPH-1000ZD3-CW-CX-W-533

DPH-1500ZD3-CW-

CX-W-533

DPH-2000ZD3-CW-CX- W-533

DPH-3000ZD3-

CW-CX- W-533



Laser (W)

1 set

TMAX1000

TMAX1500



TMAX2000



TMAX3000



Cooling-Water Machine

1 set

HL-1000

HL-1500

HL-2000



HL-3000



Welding Head

(Including CCD +

Monitor)

1 set

ND26/ND15(Optional)

ND26/ND15(Optional)



ND26/ND24(Optional)



ND40/ND24(Optional)



XYZ Axis Stroke mm

(Stroke can be customized)

1 set

500*300*300

500*300*300



500*300*300



500*300*300



Control System (Optional)

1 set

C6L Four Axis/C6S Six  Axis

C6L Four Axis/C6S Six  Axis



C6L Four Axis/C6S Six  Axis



C6L Four Axis/C6S Six Axis



Industrial Computer



1 set



PCI Computer keyboard and mouse with display



Servo (XY Axis)



2 sets



Panasonic 400W large inertia (including driver), 1 set of XY



Servo (Z Axis)



1 set



Panasonic 400W large inertia belt brake (including driver)


Model Description:

555 means the stroke is 500 * 500 * 500

ZD3 is 3-axis and ZD4 is 4-axis. It is customized according to customer requirements. Non standard fixtures are made by our  professional engineers and teams
