5000A/8000A Automatic Single Rotary Head Spot Welding Machine With Host Computer Program For Various Battery Production


Contact Person:Louis Yang

Email: Louis@chinabatterymachine.com

Tel:+86 13003860308
Whatsapp: +86 13003860308
Wechat:18659217588

  • Item No.:

    LITH-ZWRD200
  • Payment:

    Credit Card, Paypal, T/T , Western Union, LC
  • Shipping port:

    Xiamen Port
  • Lead Time:

    5 days

New Products

  • Product Details

5000A/8000A Automatic Single Rotary Head Spot Welding Machine With Host Computer Program For Various Battery Production


Features

Spot welding machine has stable performance, can be used in various battery types and multiple battery pack processing, convenient and fast fixture replacement, beautiful appearance, all aluminum alloy body.



Performance Features

1. Touch screen display, more convenient operation and clearer display.

2. Three file programming modes, manual input, array, CAD drawing import, simple and fast response to various complex program editing.

3. The welding head has the function of air cooling or water cooling, which can effectively reduce the impact of spot welding needle temperature on welding quality. 4. It can store up to 99 groups of files, which is easy to use and does not need complicated process of line changing and machine adjusting.

5.The spot welding program of side and B side of fixture can be switchedAll of our E Bikes Battery Assembly are greatly appreciated in a variety of different markets throughout the world.


Specification

Product

Single Side Automatic Spot Welding Machine

Number of storable filegroups

99

Model

LITH-ZWRD200

Operate System

Embedded system + man machine interface

Y-axis Travel

500mm

(can be customized)

X-axis Travel

400mm

(can be customized)

Driving mode

Stepper motor / servo motor

Repeated Positioning Accuracy

±0.02mm

Max Welding Speed

0.35s/spot, 2800pcs/h

Power

2000W

Max Motor Speed

1000mm/s

Weight

200kg

Max Battery Number

X:26

Y:26

Maximum bearing weight of Y-axis

50kg

Rotation Function of Welding Head

The welding head supports positive and negative rotation, and is suitable for spot welding of special-shaped batteries and anti-sticking needle function.

Welding Material

Pure nickel strip: 0.03-0.2mm



Nickel-plated steel strip :0.03-0.3mm
