0.2L-16L Laboratory Small Vertical Semicircular Planetary Ball Mill Machine For Material Grinding
Introduction
Through professional appearance design, the shell is made of high-precision die stamping, which is elegant and exquisite, high-end and stable. The planetary disk is cast, the structural components are processed by numerical control processing technology, the transmission gear is made of high-temperature wear-resistant nonmetal and metal combination precision gear, and the nitriding metal heat treatment process ensures the wear resistance of rotating shaft parts, prevents shaft breakage and ensures the high equipment height When running at high speed, it is stable and quiet, and the grinding tank fixing device can simultaneously lock and prevent loosening, which is convenient, safe and reliable.
Technical parameters
|
Transmission mode
|
Gear drive
|
|
Maximum sample loading
|
2/3 of the capacity of the ball mill
|
|
Feed size
|
Soil material≤10mm, other materials≤3mm
|
|
Discharge particle size
|
Up to 0.1um minimum
|
|
Speed regulation mode
|
Stepless speed regulation of frequency converter
|
|
Model
|
Machine volume(L)
|
Applicable standard jar volume
|
Applicable jar quantity
|
Applicable vacuum jar volume
|
Power
(kW)
|
Runing time(min)
|
|
XQM-0.2
|
0.2
|
10-50mL
|
4
|
10ml
|
0.09
|
1-9999
|
|
XQM-0.4
|
0.4
|
50-100ml
|
4
|
50ml
|
0.25
|
1-9999
|
|
XQM-1
|
1
|
50-250mL
|
4
|
50-100ml
|
0.75
|
1-9999
|
|
XQM-2
|
2
|
50-500ml
|
4
|
50-250ml
|
0.75
|
1-9999
|
|
XQM-4
|
4
|
250-1000ml
|
4
|
50-1000ml
|
0.75
|
1-9999
|
|
XQM-8
|
8
|
1-2L
|
4
|
50-2000ml
|
1.5
|
1-9999
|
|
XQM-10
|
10
|
1-2.5L
|
4
|
1-2L
|
1.5
|
1-9999
|
|
XQM-12
|
12
|
1-3L
|
4
|
1-2L
|
2.2
|
1-9999
|
|
XQM-16
|
16
|
2-4L
|
4
|
1-3L
|
3
|
1-9999
|
|
Model
|
Alternate operation time
|
Revolution
speed(rpm)
|
Rotation speed(rpm)
|
Machine weight(kg)
|
Machine dimensions(mm)
|
Noise≤db
|
|
XQM-0.2
|
1-999min
|
60-580
|
120-1160
|
18
|
430X250X270
|
50±5
|
|
XQM-0.4
|
1-999min
|
47-465
|
94-930
|
26
|
520X300X420
|
55±5
|
|
XQM-1
|
1-999min
|
35-370
|
70-740
|
74
|
740X470X600
|
60±5
|
|
XQM-2
|
1-999min
|
35-370
|
70-740
|
74
|
740X470X600
|
60±5
|
|
XQM-4
|
1-999min
|
35-370
|
70-740
|
80
|
740X470X600
|
60±5
|
|
XQM-8
|
1-999min
|
35-320
|
70-640
|
132
|
870X560X680
|
60±5
|
|
XQM-10
|
1-999min
|
35-320
|
70-640
|
138
|
870X560X680
|
60±5
|
|
XQM-12
|
1-999min
|
35-320
|
70-640
|
140
|
870X560X680
|
60±5
|
|
XQM-16
|
1-999min
|
35-255
|
70-510
|
200
|
940X600X710
|
65±5
|
